xii
P7F-E specifications summary
*Specifications are subject to change without notice.
Storage SATA Controller Intel ® 3420:
6* SATA2 300MB/s ports-
Intel Matrix Storage utility supports software
RAID 0, 1, 10 & 5 (Windows)
LSI MegaRAID driver supports software RAID 0,
1& 10 (Windows & Linux)
SAS Controller Optional:
ASUS PIKE 1064E 4-port SAS card
(Support FW RAID 0,1,1E)
ASUS PIKE 1068E 8-port SAS card
(support FW RAID 0, 1, 1E)
ASUS PIKE 1078 8-port SAS card
(support integrated H/W RAID 0, 1, 10, 5, 50, 6,
60)
ASUS PIKE 6480 8-port SAS card
(Support FW RAID 0,1,10, 5)
Networking LAN 2 * Intel 82574L + 1 * Mgmt LAN
Graphics VGA Aspeed AST2050 8MB
Onboard I/O
Connectors
PSU Connector 24-pin ATX power connector + 8-pin ATX 12V
power connector
USB Connectors 3 (support 5 USB port)
(One for internal Type A USB connector)
Fan Header 5* 4pin
SMBus 1
Chassis Intruder 1
Serial Port Header 1
Rear I/O
Connectors
External Serial Port 1
External USB Port 2
VGA Port 1
RJ-45 3 (one for iKVM)
PS/2 KB/Mouse 1
Management
Solution
Software ASWM 2.0
Out of Band Remote
Management
Optional ASMB4-iKVM for KVM-over-Internet
Monitoring CPU Temperature V
FAN RPM V
Environment Operation temperature: 10℃—35℃
Non operation temperature: -40℃—70℃
Non operation humidity: 20%—90%
(Non condensing)
