Chapter 5: RAID configuration

5. Press again, the virtual drive information appears including a

Virtual

Drive menu that allows you to change the virtual drive parameters.

Management Menu

Configure

Initialize

Objects

Rebuild

Check Consistency

PORT #

DNLIN A00-00

DNLIN A00-01

0
1

LSI Software RAID Configuration Utility Ver A.62 Apr 29, 2009

BIOS Version A.09.04300936R

Easy Configuration - ARRAY SELECTION MENU

Virtual Drive(s) Configured

LD RAID Size #Stripes StripSz Status

0 1 77247MB 2 64 KB ONLINE

Virgual Drive 0

RAID = 1

Size = 77247MB

DWC = Off

RA = On

Accept

SPAN = NO

Choose RAID Level For This VD

Cursor Keys, SPACE-(De)Select F2-ChIdInfo F3-SlotInfo F10-Configure Esc-Quit

6. Select

RAID from the Virtual Drive sub-menu, and then press .

7. Select the

RAID level from the menu, and then press .
