Operating instructions for DALI CON 1 – 10V LI

Page 3/4

Technical data

Designation:

Converter from DALI to 1-10V

Type:

DALI CON 1 – 10V LI

Mains voltage:

230Vac 50/60 Hz, DC not permitted

Power consumption:

approx. 1 W

Fuse protection:

External max. 10 A, (load contact is connected internally to L)

Operating temperature:

0°C to 45°C

Protection class/type of protection:

I (protective earth)/IP20

Pollution severity:

2 (dry not conductive)

Load contact L` (µ):

Relay contact internal (make contact), connected internally with L

Function switching (on/off), no reliable isolation (µ contact gap)

Load capacity L` (µ):

max. 10 A~ ohmic load

max. 5A~ ECG load
30 St.

EVG HF 1x 18W or 1x36W or

20 St.

EVG HF 2x18W or 2x36W or

15 St. QTi DIM 1x14/24 or 1x18 or 1x21/39 or 1x28/54 or 1x36 or 1x58 or
15 St. QTi DIM 3x18 or
10 St. QTi DIM 1x35/49/80 or 2x14/24 or 2x18 or 3x14/24 or 4x18 or
8 St. QTi DIM 2x21/39 or 2x28/54 or 2x35/49 or 2x36 or 2x58 or 4x14/24 or
5 St. QTi DIM 2x35/49/80

Output out:

1-10V max. -100mA DC, current sink (approx. 100 ECG or electronic
transformers– see manufacturers' data–)

Control voltage:

0-10V max. +3mA DC (power dimmers –see manufacturers' data–)

Dimming curve:

Switchable between: linear 0-10V and logarithmic 1-10V characteristic

DALI interface:

Acc. DALI standard, current input <2mA DC, interface non-polarised

Switch input (T):

Switch (make contact) for mains voltage (230Vac)

Terminals:

Plug-in terminals, single-wire: 0.3 - 1.5 mm

, fine-wire 0.3 – 1.0 mm

Mains:

L, N, PE

Terminal no.

(3, 2, 1)

Load contact:

→ L` (µ)

Terminal no.

(4) internal to L

DALI interface:

DA, DA

Terminal no.

(6, 7)

non-polarised

Switch input:

Terminal no.

(5)

Output out:

0-10V 1-10V DC +, -

Terminal no.

(9, 10)

polarised

Terminal 8:

Terminal no. (8) must not be used.

Maximum cable lengths :

DALI wire

Î see data sheet of the corresponding controller

Push button and 0-10V/1-10V input

Î 100m

Cable routes:

The relevant wiring requirements governing cable routes, insulation,

fusing and minimum cross-sections must be observed.

Housing:

Metal casing for installation in luminaires with screw fastening,
hole spacing 180 mm

Dimensions:

WxHxD=189 x 30 x 29 mm, see dimensional drawing

Weight:

approx. 190g

Labelling:

Terminal assignment: See wiring diagrams and information printed on unit
