Power Module
5
MG06400D-BN1MM
600V IGBT Family
Figure 13: Transient Thermal Impedance of IGBT
10 -1 10 -2 10 -3
1
10 -1
10 -2
10 -3
10 -4
10 -4
Z thJC
(K/W)
1
Rectangular Pulse Duration (seconds)
Figure 14:Transient Thermal Impedance of Diode
10 -4
10 -4
10 -3
10 -3
10 -2
10 -2
10 -1
10 -1 1
1
Z
thJC
(K/W)
Rectangular Pulse Duration (seconds)
Dimensions-Package D Circuit Diagram and Pin Assignment
