Littelfuse MG06400D-BN1MM Series - Manual

©2013 Littelfuse, Inc
Specifications are subject to change without notice.
Revised:08/06/13
Power Module
1
MG06400D-BN1MM
600V IGBT Family
Features
Applications
• Ultra low loss
• High ruggedness
• High short circuit
capability
• Positive temperature
coefficient
• Motor drives
• Inverter
• Converter • SMPS and UPS
• Welder
• Induction Heating
Absolute Maximum Ratings (T
C
= 25°C, unless otherwise specified)
Symbol Parameters Test Conditions Values Unit
IGBT
V
CES
Collector - Emitter Voltage 600 V
V
GES
Gate - Emitter Voltage ±20 V
I
C
DC Collector Current
T
C
=25°C 460 A
T
C
=50°C 400 A
I
Cpuls
Pulsed Collector Current
T
C
=25°C, t
p
=1ms 920 A
T
C
=50°C, t
p
=1ms 800 A
P
tot
Power Dissipation Per IGBT 1400 W
Free-Wheeling Diode
V
RRM
Repetitive Reverse Voltage 600 V
I
F(AV)
Average Forward Current
T
C
=25°C 400 A
T
C
=50°C 320 A
I
F(RMS)
RMS Forward Current 570 A
I
FSM
Non-Repetitive Surge
Forward Current
T
Vj
=45°C, t=10ms, Sine 1200 A
T
Vj
=45°C, t=8.3ms, Sine 1320 A
Module Characteristics (T
C
= 25°C, unless otherwise specified)
Symbol Parameters Test Conditions Min Typ Max Unit
T
Vj max)
Max. Junction Temperature 150 °C
T
Vj op
Operating Temperature -40 150 °C
T
STG
Storage Temperature Range -40 125 °C
V
isol
Insulation Test Voltage AC, t=1min 3000 V
CTI Comparative Tracking Index
Module case exposed to 0.1% ammonium
chloride solution per UL and IEC standards
350 V
R
thJC
Junction-to-Case Thermal
Resistance
Per IGBT
0.09
K/W
R
thJCD
Junction-to-Case Thermal
Resistance
Per Inverse Diode 0.15 K/W
Torque Module-to-Sink Recommended (M6) 3 5 N·m
Torque Module Electrodes Recommended (M6) 2.5 5 N·m
Weight 310 g
Life Support Note:
Not Intended for Use in Life Support or Life Saving Applications
The products shown herein are not designed for use in life sustaining or life saving
applications unless otherwise expressly indicated.
MG06400D-BN1MM Series 400A Dual IGBT
RoHS
AGENCY AGENCY FILE NUMBER
E71639
Agency Approvals
