Teccor ® brand Thyristors
25 Amp Standard & Alternistor (High Commutation) Triacs
Qxx25xx & Qxx25xHx Series
Electrical Characteristics (T
J
= 25°C, unless otherwise specified) — Standard Triac
Symbol Test Conditions Quadrant
Value
Unit
Qxx25R5
Qxx25N5
Qxx25P5
I
GT
V
D
= 12V; R
L
= 60 :
*o**o*** MAX. 50
mA
IV TYP. 120
V
GT
*o**o*** MAX. 1.3
V
IV TYP. 2.5
V
GD
V
D
= V
DRM
; R
L
= 3.3 k : ; T
J
= 125°C ALL MIN. 0.2 V
I
H
I
T
= 400mA (initial) MAX. 100 50 mA
dv/dt
V
D
= V
DRM
; Gate Open; T
J
= 125°C
400V
MIN.
275 —
V/μs
600V 225 475
800V 200 400
V
D
= V
DRM
; Gate Open; T
J
= 100°C 1000V 200 —
(dv/dt)c (di/dt)c = 13.3 A/ms; T
J
= 125°C MIN. 5 V/μs
t
gt
I
G
= 2 x I
GT
; PW = 15μs; I
T
= 35.4 A TYP. 4 3 μs
Symbol Test Conditions Quadrant
Value
Unit Qxx25RH5
Qxx25LH5
Qxx25NH5
Qxx25R6
Qxx25L6
Qxx25NH6
Qxx25K6
Qxx25J6
I
GT
V
D
= 12V; R
L
= 60 :
*o**o*** MAX. 50 80 mA
V
GT
*o**o*** MAX. 1.3 V
V
GD
V
D
= V
DRM
; R
L
= 3.3 k : ; T
J
= 125°C *o**o*** MIN. 0.2 V
I
H
I
T
= 400mA (initial) MAX. 50 100 mA
dv/dt
V
D
= V
DRM
; Gate Open; T
J
= 125°C
400V
MIN.
575 600
V/μs
600V 500 600
800V 400 475
V
D
= V
DRM
; Gate Open; T
J
= 100°C 1000V — 400
(dv/dt)c (di/dt)c = 13.3 A/ms; T
J
= 125°C MIN. 20 30 V/μs
t
gt
I
G
= 2 x I
GT
; PW = 15μs; I
T
= 35.4 A TYP. 3 5 μs
Electrical Characteristics (T
J
= 25°C, unless otherwise specified) — Alternistor Triac
Symbol Test Conditions
Value
Unit
Qxx25R5
Qxx25N5
Qxx25xH5
Qxx25x6
Qxx25NH6
Qxx25P5
V
TM
I
T
= 35.4A; t
p
= 380 μs MAX. 1.8 1.4 V
I
DRM
/ I
RRM
V
DRM
/ V
RRM
T
J
= 25°C
o7
MAX.
10 100
μA
1000V 20 —
T
J
= 100°C
o7 500 —
1000V 1000 —
T
J
= 125°C o7 2000 5000
Note: xx = voltage, x = package
Static Characteristics
