Teccor ® brand Thyristors
25 Amp Standard & Alternistor (High Commutation) Triacs
Qxx25xx & Qxx25xHx Series
Product Selector
Packing Options
Part Number
Voltage Gate Sensitivity Quadrants
Package
400V 600V 800V 1000V I - II - III IV
Qxx25R5 X X X X 50 mA 120 mA (TYP) TO-220R
Qxx25N5 X X X X 50 mA 120 mA (TYP) TO-263 D 2 -Pak
Qxx25P5 X X 50 mA 120 mA (TYP) Fastpak
Qxx25RH5 X X X 50 mA TO-220R
Qxx25LH5 X X X 50 mA TO-220L
Qxx25NH5 X X X 50 mA TO-263 D 2 -Pak
Qxx25R6 X X X X 80 mA TO-220R
Qxx25L6 X X X X 80 mA TO-220L
Qxx25NH6 X X X X 80 mA TO-263 D 2 -Pak
Qxx25J6 X X X 80 mA TO-218X
Qxx25K6 X X X X 80 mA TO-218AC
Part Number Marking Weight Packing Mode Base Quantity
Qxx25R5 Qxx25R5 2.20g Bulk 500
Qxx25R5TP Qxx25R5 2.20g Tube 500 (50 per tube)
Qxx25N5TP Qxx25N5 1.60g Tube 500 (50 per tube)
Qxx25N5RP Qxx25N5 1.60g Embossed Carrier 500
Qxx25RH5 Qxx25RH5 2.20g Bulk 500
Qxx25RH5TP Qxx25RH5 2.20g Tube 500 (50 per tube)
Qxx25LH5 Qxx25LH5 2.20g Bulk 500
Qxx25LH5TP Qxx25LH5 2.20g Tube 500 (50 per tube)
Qxx25NH5TP Qxx25NH5 1.60g Tube 500 (50 per tube)
Qxx25NH5RP Qxx25NH5 1.60g Embossed Carrier 500
Qxx25P5 Qxx25P5 21.4g Bulk 200
Qxx25R6 Qxx25R6 2.20g Bulk 500
Qxx25R6TP Qxx25R6 2.20g Tube 500 (50 per tube)
Qxx25L6 Qxx25L6 2.20g Bulk 500
Qxx25L6TP Qxx25L6 2.20g Tube 500 (50 per tube)
Qxx25NH6TP Qxx25NH6 1.60g Tube 500 (50 per tube)
Qxx25NH6RP Qxx25NH6 1.60g Embossed Carrier 500
Qxx25J6TP Qxx25J6 5.23g Tube 250 (25 per tube)
Qxx25K6TP Qxx25K6 4.40g Tube 250 (25 per tube)
