Teccor, Brand thyristors, Ev series 0.8 amp sensitive scrs – Littelfuse SxX8xSx Series User Manual
Page 9: Sot-89 reel pack (rp1) specifications, Sot-89 reel pack (rp) specifications
207
Revised: 09/23/13
©2013 Littelfuse, Inc
Specifications are subject to change without notice.
Teccor
®
brand Thyristors
EV Series 0.8 Amp Sensitive SCRs
SxX8xSx Series
SOT-89 Reel Pack (RP1) Specifications
4mm
8mm
1.5mm
13 mm Abor
Hole Diameter
180 mm
13.4 mm
2mm
12mm
ANODE
GATE
ANODE
1.75mm
5.5mm
DIRECTION OF FEED
CATHODE
Ф
SOT-89 Reel Pack (RP) Specifications
4 mm
8 mm
Ø1.5 mm
13 mm Abor
Hole Diameter
180 mm
13.4 mm
2 mm
12 mm
GATE
CATHODE
ANODE
ANODE
1.75 mm
5.5 mm
DIRECTION OF FEED
