Teccor
®
brand Thyristors
EV Series 0.8 Amp Sensitive SCRs
SxX8xSx Series
Electrical Characteristics
(T
J
= 25°C, unless otherwise specified)
Symbol
Description
Test Conditions
Limit
Value
Unit
SxX8yS1
SxX8yS2
SxX8yS
I
GT
DC Gate Trigger Current
V
D
= 6V
R
L
= 100
:
MIN.
0.5
1
15
μA
MAX.
5
50
200
μA
V
GT
DC Gate Trigger Voltage
V
D
= 6V
R
L
= 100
:
MAX.
0.8
V
V
GRM
Peak Reverse Gate Voltage
I
RG
= 10μA
MIN.
5
V
I
H
Holding Current
R
GK
= 1 KΩ
Initial Current = 20mA
MAX.
5
mA
(dv/dt)s
Critical Rate-of-Rise of
Off-State Voltage
T
J
= 125°C
V
D
= V
DRM
/V
RRM
Exp. Waveform
R
GK
=1 k
:
MIN.
75
V/μs
V
GD
Gate Non-Trigger Voltage
V
D
= V
DRM
R
GK
=1 k
:
T
J
= 25°C
MIN.
0.2
V
t
q
Turn-Off Time
T
J
= 25°C @ 600 V
R
GK
=1 k
:
MAX.
30
25
25
μs
t
gt
Turn-On Time
I
G
=10mA
PW = 15μsec
I
T
= 1.6A(pk)
TYP.
2.0
2.0
2.0
μs
Static Characteristics
(T
J
= 25°C, unless otherwise specified)
Symbol
Description
Test Conditions
Limit
Value
Unit
V
TM
Peak On-State Voltage
I
TM
= 1.6A (pk)
MAX.
1.70
V
I
DRM
Off-State Current, Peak Repetitive
T
J
= 25°C @ V
D
= V
DRM
R
GK
=1 k
:
MAX.
3
μA
T
J
= 125°C @ VD = V
DRM
R
GK
=1 k
:
MAX.
500
μA
Thermal Resistances
Symbol
Description
Test Conditions
Value
Unit
R
th(j-c)
Junction to case (AC)
I
T
= 0.8A
(RMS)
1
TO-92
75
°C/ W
SOT-223
30
°C/ W
SOT-89
50
°C/ W
R
th(j-a)
Junction to ambient
I
T
= 0.8A
(RMS)
1
TO-92
150
°C/ W
SOT-223
60
°C/ W
SOT-89
90
°C/ W
1
60Hz AC resistive load condition, 100% conduction.
Note: x = voltage, y = package
