Page 14
3.3 Navigating the EQ Section
The EQ button
toggles through
the EQs used in
each channel of
the selected
preset menu.
PEQ
GEQ
or
Navigating the "EQ Section"
To edit the parameters of the EQs used in a selected preset, simply use the following procedure. From preset mode,
press the EQ button to reach the EQ module to be edited. Successive presses of the EQ button toggle between the input and the output EQ.
Navigate through the Pages of the selected EQ section by depressing "Next Page" or "Prev Page" successively until arriving at the desired Page.
GEQ
On/Off
Flatten/Restore
EQ
Frequency
Gain -12dB to12dB
PEQ On/Off
Flatten/Restore
Bell,HSelf, LShelf, LHShelf,
Band 1 Freq
Gain -12dB to12dB
Q .20 to 16.0
Band 2 Freq
Gain -12dB to12dB
Q .20 to 16.0
Band 3 Freq
Gain -12dB to12dB
Q .20 to 16.0
Successive presses of the Data Wheel will toggle between
parameters within the currently selected page.
GEQ/PEQ
3.4 Navigating the Subharmonic Section
The PREV PG and NEXT PG
buttons scroll through
the pages of selected module.
NEXT PG> Navigating the Subharmonic Synthesizer Section Subharmonic - -On/Off 24-36Hz Level - 0% - 100% SUBHARMONIC SUBHARMONIC From preset mode, press the SUBHARMONIC button. Pressing the Data Wheel will select the parameter to be edited. Successive presses of the Data Wheel will toggle between parameters within the currently selected page. Section 3 Editing Functions 10 DriveRack ® PA+
Subharmonics % 0-100
36-56Hz Level - 0% - 100%
