Make output connections from the six output XLR connectors on the back panel to the •
input of the selected power amplifiers. (Low out to low amp, mid out to mid amp and
high out to high amp as needed)
If you will be “pinking” (Auto-EQing) the room through the use of the pink noise •
generator, RTA microphone and the Auto-EQ Wizard, connect the RTA microphone to the
front-panel XLR input.
IMPORTANT- It is essential that the power amps are turned off prior to cycling power •
to the DriveRack® PA+. It is standard practice to make sure that your power amps are
the last item turned on and the first turned off.
Once all of the connections have been made and the unit is powered up, you can navigate
through the entire signal path of the DriveRack PA+ from the front panel of the unit. The
display provides you with a clear and concise overview of each aspect of the signal path from
the input to the output section.
