Alarm
Sensor Input 4ch (NC/NO Selectable)
Alarm Output 1 Alarm out
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Analog
Resolution
D1 120fps 120fps 120fps
Half D1 120fps 240fps 240fps
CIF 120fps 240fps 480fps
HD
Resolution
1280X720 - - -
1920X1080 - - -
Recording quality grade 5 Grades
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution
Yes
Pre Recording Min. 15 seconds and Max. 20 minutes
Post Recording Min. 10 seconds and Max. 60 seconds
Display Frame Rate Real time
Playback
Multi-Decoding 1, 4 1, 4, 8 1, 4, 8, 16
Playback Speed x1/4 ~ x32 x1/4 ~ x16 x1/4 ~ x8
Search Mode Timeline, Event, Archive, Log
Storage
HDD
Interface Type Serial ATA I
Capacity of 1 HDD 2TB
Internal HDD Number 1EA (2EA without DVD-RW)
ESATA 1
Backup
USB Flash drive Video & Still Image
USB External HDD Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F
Menu Display GUI
Input Method Mouse, Front Buttons, Remote control, Key Board
Serial PTZ control 1 RS-485
Termination -
Console (RS-232C) 1 (for Development use only, Reserved for POS)
Network
Dynamic DNS Yes
Network Interface 10/100 base-TX Ethernet (RJ-45)
Network Streaming CIF @ 60fps CIF @ 120fps CIF @ 240fps
Network
Access
Web viewer (1:1)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW (1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
