USB External HDD Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F
Menu Display GUI
Input Method Mouse, Remote control
Serial PTZ control -
Termination -
Console (RS-232C) -
Network
Dynamic DNS Yes
Network Interface 10/100 base-TX Ethernet (RJ-45)
Network Streaming CIF @ 60fps CIF @ 120fps
Network
Access
Web viewer (1:1)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW (1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
Features
DLS (Day Light Saving) Yes
Internal Beep By Alarm, Motion, Video Loss, HDD error
S/W Upgrade USB Flash drive, Remote Network
NTP Yes
Power Power Supply Voltage DC 12V 2.5A DC 12V 5A
Allowable operation temperature 5°C - 40°C
Allowable operation humidity 0 - 90 %
Weight Unit Weight (Gross weight) 2.8 Lbs (4.4 Lbs) 3 Lbs (4.6 Lbs) 3.4 Lbs (6.6 Lbs)
Dimension Unit Dimension (W x H x D) 10.6" x 7.5" x 1.8" 10.6" x 7.5" x 1.8" 13.3" x 10.2" x 2.5"
3-2. VVR4004HMFD, VVR4008HM, VVR4016HM
Model
VVR4004HMFD VVR4008HM VVR4016HM
Recording Performance D1 * 120FPS Half D1 * 240FPS CIF * 480FPS
Video
Input
Channel 4 channels 8 channels 16 channels
Input Level Composite, 1.0Vp-p, 75ohm
Output
VGA 1 VGA (Max. 1080p)
HDMI 1 HDMI (Max. 1080p)
HD-SDI -
LOOP -
BNC 1 channel
SPOT 1 channel
Audio
Input & Output 4 Line input & 1 Line output
Audio Codec G.711 (ADPCM)
