Derale Performance, Los Angeles, CA

800.421.6288 www.derale.com

Warning: Installation of accessories should only be undertaken by those with mechanical knowledge and are familiar with working on
vehicles. Always use eye protection (goggles, safety glasses or shield). Park the vehicle in a well lit area, on level ground and apply the
parking brake. Only work on a cold vehicle that has been sitting overnight, failure to do so will result in severe burns and injury. Before starting
the vehicle, make sure no tools or any other items are left under hood that could interfere with or be drawn into moving parts of the engine.
Failure to follow instructions can lead to severe damage and personal injury.

(Page 4)

RELAY WIRE HARNESS
BLACK Wire:
Using a Red #10 Ring Terminal and #10 Sheet Metal Screw supplied, attach the Black wire to a good Chassis
Ground (-).
RED Wire: Using the Blue 5/16” Ring Terminal, attach the Red wire directly to Positive (+) terminal on the vehicles battery.
YELLOW Wire: Using a Blue Butt Connector, Blue Female Connector & extra wire supplied, attach the Yellow wire to EITHER
terminal on the Thermostat Switch.
GREEN Wire-Override Circuit (Optional):
The Green wire is designed to work in two different configurations. When used, this will allow the fan to be turned on
regardless of the temperature of the Thermostat Switch as it simply overrides all other functions. If you choose not to use this
option, cut any exposed copper and tape or shrink tube the end of the wire.
ORANGE Wire: Using a Blue Butt Connector supplied, attach the Orange wire to the Grey wire on the Electric Fan Assembly.
BLUE Wire: Using a Blue Butt Connector supplied, attach the Blue wire to the Brown wire on the Electric Fan Assembly.
A/C Override – Using a Blue Wire Tap supplied, attach the Green wire to the Positive (+) lead on the vehicles air conditioning
compressor.
Manual Switch Override –

.

Attach the Green wire to the proper terminal on the Manual Switch (Not provided)

For Manual Switch installation, refer to manufacturer’s instruction manual.

VEHICLE TESTING

1.

Before starting the vehicle, make sure all wires are safely zip tied and away from HOT or moving components.

2.

Start the vehicle.

3.

If the Override function is being used, either turn on the vehicles air conditioning or flip the manual switch to the ON

position. The electric fan should start immediately.

4.

Turn off the Override function and allow the engine to warm up to operating temperature.

5.

Allow fan to turn on and cycle off before test driving the vehicle.

TROUBLESHOOTING Q&A

Q: Why doesn’t the electric fan turn on when I use the Override function?
A: To quickly test the Override function, disconnect the Green wire and run a jumper wire directly to the Positive (+) terminal on

the battery. The electric fan should start immediately. If fan started, reattach the Green wire to the proper (+) wire on the A/C
Compressor or Manual Switch.

Q: Why doesn’t the fan turn on automatically?
A: The Thermostat Switch is 100% tested from the factory.

1. Check all electrical connections.
2. Check the Chassis Ground connections to make sure all paint is sanded off and you are getting a good metal to metal

contact.

Q: Why does the electric fan run after the vehicle has been turned off?
A: Check the wire going from the Thermostat Switch to the Ignition Switch. This wire is most likely connected to a constant

Power source. Disconnect the wire and attach it to a Switched 12V Ignition source.

(Wiring Continuted)
