Table 16. TMU Trolley
Item Qty.
C1
<1000kg C2
<2000kg C3
<3200kg C5
<5000kg Description
1+3+4+5+6 1 52329486 52329491 52329494 52329496
Side
plate
assembly
-
idler
1+2+4+5+6 1 52329489 52329493 52329495 52300010
Side
plate
assembly
-
drive
7+9+10+11+24 1 52329498
-
-
-
Cross head assembly = 2.28-3.94 in. 55-
100 mm
7+9+10+11+24 1 52329499
-
-
-
Cross head assembly = 4.17-5.90 in.
106-150 mm
7+9+10+11+24 1 52329501
-
-
-
Cross head assembly = 6.10-7.87 in.
155-200 mm
7+9+10+11+24 1 52329502
-
-
-
Cross head assembly = 8.11-9.76 in.
206-248 mm
7+9+10+11+24 1 52329503
-
-
-
Cross head assembly = 10.23-12.09 in.
260-307 mm
7+9+10+11+24 1
- 52329506 -
-
Cross head assembly = 2.54-4.96 in. 64-
126 mm
7+9+10+11+24 1
- 52329507 -
-
Cross head assembly = 5.16-7.48 in.
131-190 mm
7+9+10+11+24 1
- 52329508 -
-
Cross head assembly = 7.80-9.76 in.
198-248mm
7+9+10+11+24 1
- 52329510 -
-
Cross head assembly = 10.24-12.2 in.
260-310 mm
7+9+10+11+24 1
-
- 52329512 -
Cross head assembly = 3.28-5.39 in. 82-
137 mm
7+9+10+11+24 1
-
- 52329513 -
Cross head assembly = 5.51-7.48 in.
140-190 mm
7+9+10+11+24 1
-
- 52329514 -
Cross head assembly = 7.80-9.76 in.
198-248 mm
7+9+10+11+24 1
-
- 52329516 -
Cross head assembly = 10.24-12.2 in.
260-310 mm
7+9+10+11+24 1
-
-
-
52329517
Cross head assembly = 3.23-4.33 in. 82-
110 mm
7+9+10+11+24 1
-
-
-
52329518
Cross head assembly = 4.45-5.91 in.
113-150 mm
7+9+10+11+24 1
-
-
-
52329519
Cross head assembly = 6.10-7.87 in.
155-200 mm
7+9+10+11+24 1
-
-
-
52329520
Cross head assembly = 8.11-9.76 in.
206-248 mm
7+9+10+11+24 1
-
-
52329521
Cross head assembly = 10.24-12. In.
260-310 mm
Item Qty.
C1
<1000kg C2
<2000kg C3
<3200kg C5
<5000kg Description
1
2
- - - -
Side
plate
2 2
558909 558919 558929 558949
Driving
wheel
with
bearings
2+4+5
2a 2
2309781002 2309782002 2309783002 2309784002
Patented track drive wheel assy
3 2
558908 558918 558928 558948
Idle
wheel
with
bearings
3+4+5
3a 2
2309781001 2309782001 2309783001 2309784001
Patented track idler wheel assy
6 4 -
-
-
- Circlips
external
7 2 -
-
-
-
Tension rod
9 - -
-
-
- Washers
10 4
831523
831540
831530
8004234 Nut
11 4
831575
831576
831577
8004208 PAL
22 2
830203 830203 830203 830203
CHC
Screw
(for
drive)
23 2
558868 -
-
- Counterweight
24 1
2222002
2222003
2277020
2182000 Adapter
(perpendicular)
25 4
558993 558993 558993 558993
Bumper
26
1 2104205001 2104205001 2104205001 2104205001
Complete
limit
switch
26a
1 50004910 50004910 50004910 50004910
Limit
switch
26b 1
558995 558995 558995 558995
Bracket
–
limit
switch
