CTA USER MANUAL

© DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED - 7 - 2007-05-09


1.7 Default Settings

There are 4 operation modes in CTA: timer, counter, tachometer and timer + counter. The table below
offers the preset parameters for all functions.

Function

Preset setting

Function

Preset setting

Select function

Timer

Select function

Tachometer

Timer mode

Up (counting up)

Output mode

2Lo1Lo

Output mode

Sond1

Counting speed

5K

Displayed unit

S 001 (0.01)

Position of decimal point 0 (no decimals)

Pulse width of output 1 0.02sec

Pre-scale value

1.000 (default)

Min. width of reset
signal

20ms

Delay time while switching
on power

0.0 (no delay)

Ti

m

er

Input signal type

NPN

Average of input data

0 (function disabled)

Select function

Counter

Min. width of reset signal 20ms

Counter mode

Stage1 (1 stage)

Ta

ch

om

et

er

Input signal type

NPN

Input mode

Up (counting up)

Select function

Mix(Timer +Counter)

Output mode

F

Input mode of timer

Up (counting up)

Counting speed

5K

Output mode of timer

Sond1

Position of decimal
point

0 (no decimals)

Displayed unit of timer

S 001(0.01)

Pre-scale value

1.000

Input mode of counter

Up (counting up)

Save data while
switching off power

Clear

Output mode of counter

F

Min. width of reset
signal

20ms

Counting speed

5K

Counter

Input signal type

NPN

Pulse width of output 1

0.02sec

Position of decimal point 0 (no decimals)

Pre-scale value

1.000 (default)

Save data while switching
off power

Clear

Min. width of reset signal 20ms

Ti

mer + Counter

Input signal type

NPN

1.8 Easy DIP Switch Setup

The tables below are the DIP switches for each mode of CTA. Please be noted that in the “timer +
counter” mode, setting up parameters by DIP switches are not allowed.

ƒ

Timer

Switch

Function

OFF

ON

1 DIP

switch

Disabled Enabled

2 Timer

mode

Counting

up

Counting

down

3
4

Output mode

See top-right
table

5
6
7

Displayed unit

See bottom-right
table

8

Width of reset signal 20ms 1ms

Switch 3

Switch 4 Output mode

OFF OFF Sond1

ON OFF Sond2

OFF ON Soffd

ON ON Son

Switch 5 Switch 6 Switch 7 Displayed unit

OFF OFF OFF

0.01 sec.

ON OFF OFF

0.1

sec.

OFF ON OFF

1

sec.

ON ON OFF

min.,

0.01

sec.

OFF

OFF

ON

min., 0.1 sec.

ON OFF ON

0.1

min.

OFF ON ON

minute

ON ON ON

hr.,

min.,

sec.
