CTA USER MANUAL

© DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED - 21 - 2007-05-09

At this time, the sensor detects the speed and sends it back to tachometer. Assume the value displayed on
the screen is 3,200rpm,

F × 60/3 = 3,200
F = 160Hz

Figure 1 Figure 2
