4.2 Enabling the Special Registers
The DSC-200/300 contains two unique registers, an Interrupt Status Register and an
Options Register. These registers are enabled when the SPAD jumper is removed (factory
default). They replace the UART Scratchpad Register on accesses to register address 7.
The Interrupt Status Register and Options Register are accessed through the scratchpad
location of either UART. The DLAB bit of the UART (Line Control Register, bit 7) is used to
select between the two registers. The most recent write of a DLAB bit in either UART selects
between the two registers as shown in Figure 8.
Scratchpad Registers applied X
Options Register removed 1
Interrupt Status Register removed 0
Register selected for
address 7 accesses
SPAD Jumper DLAB Bit
Figure 8 --- DLAB bit selects between special registers
4.3 Interrupt Status Register
The read-only Interrupt Status Register can be used to quickly identify which serial ports
require servicing after an interrupt. Reading the Interrupt Status Register will return the interrupt
status of the entire DSC-200/300, as shown in Figure 9. The individual bits are cleared as the
interrupting ports are serviced. The interrupt service routine should ensure that the interrupt
status register reads zero before exiting.
Port 1 --- 1 if interrupt pending 0
Port 2 --- 1 if interrupt pending 1
0 (not used) 2
0 (not used) 3
0 (not used) 4
0 (not used) 5
0 (not used) 6
0 (not used) 7 (MSB)
Description Bit
Figure 9 --- Interrupt Status Register
Quatech DSC-200/300 User's Manual 14
