Hardware Installation
15 Manual Documentation Number EIR405-T – 0912m
www.bb-elec.com
www.bb-europe.com
3. Apply power to the switch. If you need help with this please refer to the Wiring the
Power Inputs section. The power LED on the switch will light up. Please refer to the LED
Indicators section for meaning of LED lights.
4. Prepare the twisted-pair, Ethernet cable for connection.
5. Insert one side of cable into one of the switches Ethernet ports and the other side of the
cable to the network device you want connected ex: switch, PC or Server. The port LED on
the Industrial switch will light up when the cable is connected to the network device. Please
refer to the LED Indicators section for LED light meaning.
6. When all connections are made and the LED lights show normal activity the installation is
complete.
