1
About the Modular Media Converters
The Modular Media Converter Series includes modules that convert copper to
single-mode or multi-mode fiber at Ethernet, Fast Ethernet and Gigabit speeds.
Modular Media Converter series chassis provide power to media converter
modules, and are available with one, four, eight or twelve slots for installing any
combination of McPIMs (10Mbps Ethernet), McLIMs (100 Mbps Fast Ethernet),
McLIM TP-TX/FX (Switching 10/100 Mbps) and McGigabit modules (1.25 Gbps
Ethernet).
Media
Converter
Description
1
Is a standalone chassis which includes one media conversion
module slot, and a fixed, internal 115/230 VAC power supply.
4
Is a standalone chassis which includes four media conversion
module slots, and a fixed, internal 120/240 VAC power supply.
8
Is a 1U high, Rackmountable chassis that includes eight media
module slots and a fixed 120/240 VAC power supply.
12
Is a Rackmountable chassis and includes twelve media conversion
module slots and a 115/230 VAC power supply. MediaConverter/12
is 1U high and has the power on the rear of the chassis with media
conversion module slots on the front. For redundancy a second
power supply maybe installed.
About McPIMs
McPIMs (Media Converter Port Interface Modules) are 10 Mbps Ethernet modules
which provide a single-conversion between 10Base-T twisted pair and 10Base-FL
single-mode or multi-mode fiber. McPIMs include one RJ-45 connector and one
pair of ST or SC fiber optic connectors. Each McPIM requires one slot in a media
converter chassis.
