1
Æ Please move the mouse to “NO.” column, and select user want to delete
row, then click it.
1
2
Æ When user finishes the step, then click the “Delete” button.
GW-7433D MODBUS TCP/CANopen Gateway Quick Start User Guide (Version 1.0, July/2008) 5
2 1
(2). RxPDO Setting
User can set the RxPDO parameters by TxPDO’s way, as follow figure.
(note: the Cycle column select always “NO”).
Cycle
(3). Read TxSDO Setting.
Key-in the index (in hex format) and subindex (in hex format) of the object
