Rainbow Electronics C105 Series - Manual

Specifications:
Contact Resistance: 30m @ 100mA DC
Insulator Resistance: 1000M min. @ 500V DC
Current Rating: 3AMP
Voltage: 1000V AC For 1 minute
Operating Temperature: -55 C~+105 C
Contact: Brass or Phosphor Bronze, Stamped
Housing: PBT, UL94V-0
Insulator Colour:
Screw Type:
0 - W/O Screws
1 - Screw #4-40
C - Chromeplated
T - Tinned
C105 - 26 F T B 0
Ordering Information
Gender:
No. of Pins:
Shell Plating:
M - Male
F - Female
Series No.
B - Blue
K - Black
W- White
C105 Series
D-Sub H.D. Dip Type, Straight
69.30
30.90
39.10
53.00
A
15
62
26
Positions
44
2.41
2.29
2.29
2.29
C
55.40
39.00
17.70
25.30
B
54.80
38.40
24.70
16.33
E
27.50
19.30
41.30
57.70
D
63.50
47.04
33.32
24.99
F
15,26,44,62
