Termination Type:
1 - Solder Eyelet
2 - Dip Solder
3 - Bus Bar
C159 - 24 1
Series No.
Specifications:
Contact Resistance: 16m @ 100mA DC
Insulator Resistance: 5000M min. @ 500V DC
Current Rating: 2AMP
Voltage: 1600V AC For 1 minute
Operating Temperature: -55 C~+105 C
Contact: Brass or Phosphor Bronze, Gold Plated
Housing: PC, UL94V-0
C159 Series
Edge Connector, 3.96mm(0.156")
Ordering Information
No. of Pins:
20,24,30,36,
44,56,72 63.55 55.44 74.52 66.78 30 80.87
36 92.78 86.43 78.69 75.46 67.32
Positions
24
20
A
68.94
64.30
B
62.59
57.64
C
54.85
47.60 44.30
51.62
D
35.64
43.56
E
65.78
77.69
F
48.20
53.85
44
56 108.66
132.48
102.31
126.13
94.57
118.39
91.34
115.16
83.16
106.92
93.57
117.39
72 157.81 164.16 146.84 150.07 149.07 138.60
