Rainbow Electronics C102 Series - Manual

<
<
2
C - Chromeplated
T - Tinned
C102 Series
D-Sub Crimp Type
Specifications:
Contact Resistance: 30m @ 100mA DC
Insulator Resistance: 1000M min. @ 500V DC
Current Rating: 5AMP
Voltage: 1000V AC For 1 minute
Operating Temperature: -55 C~+105 C
Contact: Brass or Phosphor Bronze, Stamped
Housing: PBT, UL94V-0
Insulator Colour:
C102 - 25 F T K 0
Ordering Information
No. of Pins:
09,15,25,37,50
Gender:
M - Male
F - Female
Shell Plating:
Series No.
B - Blue
K - Black
A Positions
09
15
25
B D C E
39.94
26.15
17.78
39.24
31.04
53.04
24.99
33.32
47.04 19.36
27.64
41.08 16.33
24.66
38.38
0 - W/O Screws
1 - Screw #4-40
Screw Type:
54.84 57.38 63.50 69.62 37 56.56
66.90 52.86 50 61.11 52.34 55.30
