ATMOS -1M60/1M30 [Preliminary]
Note: RO: Read Only register, WO: Write Only register, RW: Read & Write register
6.3.2 Camera Settings Memory
ATMOS cameras have 5 banks to save settings:
• Bank 0 contains the factory settings. This bank cannot be modified by the user
• Bank 1 to 4 are used to store 4 different settings
• Bank 1 might be protected by an advanced user (see Register @ 104H). Contact Atmel for
details
300 1 WO -
Gamma correction:
[5:0] = gamma settings; value from 0.125
(= 1) to 7.875 (= 63) in Q6.3 representation
1000 1312 151F RW - 0
FPN coefficients (8-bit):
Format: Fpn [0]; Fpn[1]; Fpn [2];…
2000 8192 3FFF RW - linear
Look-up table (4096 × 16-bit):
Format: Lut [0]; Lut [1]; … ; Lut [4095]
value: 0 to 4095
Table 6-6. Internal Register Mapping (Continued)
Start Addr
(Hex)
Size
Dec)
End
Addr (Hex)
Access Type
Processing Internal Task
Factory
Settings Description
