ATV2500B(Q)(L)
6
Note: 1. See I
CC
versus frequency characterization curves.
DC Characteristics
Symbol Parameter Condition Min Typ Max Units
I
IL
Input Load Current V
IN
= -0.1V to V
CC
+ 1V 10 µA
I
LO
Output Leakage
Current
V
OUT
= -0.1V to V
CC
+ 0.1V 10 µA
I
CC
Power Supply
Current,
Standby
V
CC
= MAX,
V
IN
= GND or
V
CC
f = 0 MHz,
Outputs Open
ATV2500B
Com. 110 190 mA
Ind., Mil. 110 210 mA
ATV2500BQ
Com. 30 70 mA
Ind., Mil. 30 85 mA
ATV2500BL
Com. 2 5 mA
Ind., Mil. 2 10 mA
ATV2500BQL
Com. 2 4 mA
Ind., Mil. 2 5 mA
I
OS
Output Short
Circuit Current
V
OUT
= 0.5V -120 mA
V
IL
Input Low Voltage MIN ≤ V
CC
≤ MAX -0.6 0.8 V
V
IH
Input High Voltage 2.0
V
CC
+
0.75
V
V
OL
Output Low
Voltage V
IN
= V
IH
or V
IL
,
V
CC
= 4.5V
I
OL
= 8 mA Com., Ind. 0.5 V
I
OL
= 6 mA Mil. 0.5 V
V
OH
Output High
Voltage
V
CC
= MIN
I
OH
= -100 µA V
CC
- 0.3 V
I
OH
= -4.0 mA 2.4
