ATV2500B(Q)(L)
17
25 12 31 ATV2500BQ-25DC
ATV2500BQ-25JC
ATV2500BQ-25KC
ATV2500BQ-25PC
40DW6
44J
44KW
40P6
Commercial
(0
°C to 70°C)
ATV2500BQ-25DI
ATV2500BQ-25JI
ATV2500BQ-25KI
ATV2500BQ-25PI
40DW6
44J
44KW
40P6
Industrial
(-40
°C to 85°C)
ATV2500BQ-25DM
ATV2500BQ-25KM
ATV2500BQ-25LM
40DW6
44KW
44LW
Military/883C
(-55 °C to 125°C)
ATV2500BQ-25DM/883
ATV2500BQ-25KM/883
ATV2500BQ-25LM/883
40DW6
44KW
44LW
Military/883C
(-55
°C to 125°C)
Class B, Fully Compliant
25 12 31 ATV2500BQL-25DC
ATV2500BQL-25JC
ATV2500BQL-25KC
ATV2500BQL-25PC
40DW6
44J
44KW
40P6
Commercial
(0
°C to 70°C)
25 12 31 ATV2500BQL-25DI
ATV2500BQL-25JI
ATV2500BQL-25KI
ATV2500BQL-25PI
40DW6
44J
44KW
40P6
Industrial
(-40 °C to 85°C)
30 15 26 ATV2500BQL-30DM
ATV2500BQL-30KM
ATV2500BQL-30LM
40DW6
44KW
44LW
Military/883C
(-55 °C to 125°C)
15 26 ATV2500BQL-30DM/883
ATV2500BQL-30KM/883
ATV2500BQL-30LM/883
40DW6
44KW
44LW
Military/883C
(-55 °C to 125°C)
Class B, Fully Compliant
Ordering Information (Continued)
t
PD
(ns)
t
COS
(ns)
Ext. f
MAXS
(MHz) Ordering Code Package Operation Range
Using “C” Product for Industrial
To use commercial product for Industrial temperature ranges, down-grade one speed grade from the “I” to the “C” device
(7 ns “C” = 10 ns “I”) and de-rate power by 30%.
Package Type
40DW6 40-pin, 0.600" Wide, Ceramic, Dual Inline Package (Cerdip)
44J 44-lead, Plastic J-leaded Chip Carrier OTP (PLCC)
44KW 44-lead, Windowed, Ceramic J-leaded Chip Carrier (JLCC)
40P6 40-pin, 0.600" Wide, Plastic, Dual Inline Package OTP (PDIP)
44LW 44-pad, Windowed, Ceramic Leadless Chip Carrier (LCC)
