16
TH7899M
2201A–IMAGE–02/02
Electrical
Performance
Notes: 1. Measured on VOS1 VOS2 VOS3 and VOS4.
2. Measured in each VDD pin.
Electrooptical
Performance
General measurement conditions (unless specified):
• TC = 25°C (package temperature).
• Vertical transfer frequency FV = 100 kHz.
• Horizontal transfer frequency and output frequency FH = 5 MHz.
Illumination conditions:
• 3200K halogen lamp + 2 mm BG38 filter + F/3.5 aperture.
Table 3. Static And Dynamic Electrical Characteristics
Parameter Symbol
Value
Unit Remarks Min Typ Max
DC Output Level (1) Vref 10.5 V VDR = 13.5V; VS = 0V
Output Impedance (1) Zout 200 230 250
Ω
Output Amplifier Supply
Current
(2)
IDD 10 mA
VDD = 15V;
VDR = 13.5V; VS = 0V
Charge to Voltage Conversion
Factor
With VGL = 1V and VDR = 13.5V
With VGL = 12V and VDR = 15V
CVF1
CVF2
6.6
4.2
7
4.5
7.4
4.7
µ V/e-
µ V/e-
For Standard Mode
For Binning Mode
Image Zone To Readout
Register Frequency
FV 100 180 kHz
Without Reduction Of
Saturation Charge
Readout Register And Reset
Frequency
FH 5 20 MHz
Table 4. Electro-optical Performance Characteristics
Parameter Symbol
Value
Unit Remarks Min Typ Max
Saturation Output Voltage
Without Binning VSAT 1.4 1.9 V (1)
Saturation Charge of Elementary
Pixel
Without Binning QSAT 220 270 ke- (1)
Saturation Charge of Readout
Registers
320 360 ke- (2)
Saturation Charge of Summing
Gates
Φ
S
550 630 ke- (2)
Saturation Level on the Output
Node
With VGL = 1V and VDR = 13.5V
With VGL = 12V and VDR = 15V
280
530
300
570
ke-
ke-
(3)
For Standard Mode
For Binning Mode
