Define GSM Context
AT#GSMCONT=0,”IP”,”
3359009000”,”0.0.0.0”
GPRS Context Activation
AT#SGACT=0,1
You have to define GSM context filling in the information of the Internet Service Provider Number.
Next step is activation of GSM context which gives as reply the IP of the module assigned by network:
AT#SGACT=0,1
#SGACT: 217.200.58.225
OK
Configuration for the module that opens connection (client):
Define PDP Context
AT+CGDCONT=1,”IP”,”ibox.tim.it”,”0.0.0.0”
GPRS Context Activation
AT#SGACT=1,1
You have to define PDP context filling in the information of APN in this example: ibox.tim.it.
Next step is activation of GPRS context which gives as reply the IP of the module assigned by
network.
AT#SGACT=1,1
#SGACT: 217.201.142.223
OK
Now, on the server side, before opening socket in listen it is possible to define an accept firewall chain
in order to filter IP of the senders.
Then with the AT command AT#SL=1,1,1024,0 the socket will be set in listen on the port #1024:
Firewall Setup
AT#FRWL=1,” 217.201.142.223”,”0.0.0.0”
Socket Listen
AT#SL=1,1,1024
On the client side, you can open the connection with the remote host with IP address 217.200.58.225
on the port 1024 (as in example):
Socket Dial
AT#SD=2,0,1024,” 217.200.58.225”
NOTE: IP of the modules can be verified with the following AT command line: AT#CGPADDR=
