Installing the 9341 Into a Frame Slot
2-2
9341 PRODUCT MANUAL
9341-OM (V4.1)
Note:
If installing the 9341 in a slot with no rear I/O module, an optional Rear
I/O Module is required before cabling can be connected. Install the Rear
I/O Module as described in Installing a Rear I/O Module (p. 2-4).
CAUTION
If required, make certain Rear I/O Module(s) are installed before installing the
9341 into the frame slot. Damage to card and/or Rear I/O Module can occur if
module installation is attempted with card already installed in slot.
Note:
Check the packaging in which the 9341 was shipped for any extra items such
as a Rear I/O Module connection label. In some cases, this label is shipped
with the card and to be installed on the Rear I/O connector bank correspond-
ing to the slot location of the card.
Install the 9341 into a frame slot as follows:
1.
Determine the slot in which the 9341 is to be installed.
2.
Open the frame front access panel.
3.
While holding the card by the card edges, align the card such that the
plastic ejector tab is on the bottom.
4.
Align the card with the top and bottom guides of the slot in which the
card is being installed.
5.
Gradually slide the card into the slot. When resistance is noticed, gently
continue pushing the card until its rear printed circuit edge terminals
engage fully into the rear I/O module mating connector.
CAUTION
If card resists fully engaging in rear I/O module mating connector, check for
alignment and proper insertion in slot tracks. Damage to card and/or rear I/O
module may occur if improper card insertion is attempted.
6.
Verify that the card is fully engaged in rear I/O module mating connector.
7.
Close the frame front access panel.
8.
Connect the input and output cables as follows:
•
If the 9341 is being installed in a frame with a rear I/O module
already in place, refer to the label on the connector bank
corresponding to the card’s slot location for connector designations.
•
If the 9341 is being installed in a frame using an optional 9341 Rear
I/O Module, connect cabling in accordance with the appropriate
diagram shown in Table 2-1, “9341 Rear I/O Modules” (p. 2-5).
9.
