Introduction
Technical Specifications
9341 Rear I/O Modules
The 9341 physically interfaces to audio connections at the rear of its frame
using a Rear I/O Module.
All inputs and outputs shown in the 9341 Functional Block Diagram (Figure
1-1) enter and exit the card via the card edge backplane connector. The Rear
I/O Module breaks out the 9341 card edge connections to BNC connectors
that interface with other components and systems in the signal chain.
These required BNC connections are provided by using an optional 9341
Rear I/O Module. The 9341 Rear I/O Modules are shown and described in
9341 Rear I/O Modules (p. 2-5) in Chapter 2, “Installation and Setup”.
Technical Specifications
Table 1-1 lists the technical specifications for the 9341 8-Channel Analog
Audio to AES Converter card.
Table 1-1
Technical Specifications
Item
Characteristic
Part number, nomenclature
9341 8-Channel Analog Audio to AES Converter
Installation/usage environment
Intended for installation and usage in frame meeting openGear®
modular system definition.
Power consumption
11 Watts maximum
Environmental:
Operating temperature:
Relative humidity (operating or storage):
32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication
10/100 Mbps Ethernet with Auto-MDIX.
Indicators
Card edge display and indicators as follows:
• 4-character alphanumeric display
• Input Channel LED indicators
Controls
Card edge switches as follows:
• Menu Enter pushbutton switch
• Menu exit pushbutton switch
• Up/down selection toggle switch
Internal Tone Generators
Four built-in tone generators, each configurable for 18 discrete sine
wave frequencies ranging from 50 Hz to 16 kHz.
Generator source signal level is equivalent to -20 dBu.
