1

Technical Specifications

1-14

9341 PRODUCT MANUAL

9341-OM (V4.1)

Analog Audio Input

Number of Inputs (maximum):

Eight, 3-wire balanced analog audio using Phoenix connectors
with removable screw terminal blocks (Phoenix PN 1803581;
Cobalt PN 5000-0013-000R)

Sampling Rate:

48 kHz

Signal Level:

+24 dBu => 0 dBFS

A/D Frequency Response:

20 – 20 kHz ± 0.25 dB

AES Audio Output

Standard:

SMPTE 276M

Number of Outputs (maximum):

4 unbalanced AES-3id pairs

Output Impedance:

75

Return Loss:

> 30 dB 100 kHz to 6 MHz

Resolution:

Up to 24-bit

Sample Rate:

48 kHz

Table 1-1

Technical Specifications — continued

Item

Characteristic
