1
Technical Specifications
1-28 9921-FS PRODUCT MANUAL 9921-FS-OM (V1.15)
Fiber Inputs/Outputs
(option required) Input/Output Complement:
Up to two inputs/outputs (maximum total between inputs and outputs)
Connectors:
Dual LC, standard polish
Fiber Type:
9/125 micron, single mode
Mating System:
Blindmate
Tx Power:
-5 dBm @ 1310 nm
Rx Power:
-16 to -3 dBm @ 1260 to 1620 nm
Analog Video Input
(option required) Input Complement:
Separate component and composite inputs on 75 Ω BNC connectors.
Supports component HD/SD and component, composite, and Y/C SD
inputs.
Video Input Types:
HD: Component YPbPr and RGB SMPTE
SD: Composite, Component YPbPr (BetaCam™, MII™,
SMPTE/N10), RGB, and Y/C
ADC Bit Depth:
12 bit
Sampling:
54 MHz (4x oversampling)
Frequency Response:
Y/CVBS: ± 0.25 dB to 30 MHz
Pb/Pr: ± 0.25 dB to 15 MHz
Noise:
< -60 dB to 30 MHz (unweighted)
Differential Phase:
<1.5°
Differential Gain:
<1.0%
Analog Video Output
(option required) Output Complement:
Separate component and composite outputs on 75 Ω BNC connectors.
Supports component HD/SD and component, composite, and Y/C SD
outputs.
Video Output Types:
HD: Component YPbPr and RGB SMPTE
SD: Composite, Component YPbPr (BetaCam™, MII™,
SMPTE/N10), RGB, and Y/C
DAC Bit Depth:
12 bit
Table 1-4 Technical Specifications — continued
Item Characteristic
