Turbosmart BLOW OFF & BYPASS VALVE KITS - Dual Port for: Nissan (Skyline GT-S and GT-R: R32, R33, R34, R35 – excluding R32GTS-t) User Manual
Page 2
2
3) Replace the standard vacuum lines with the hose provided in each kit. Use the spring clamps to secure the lines.
4) Start the car and check for leaks. Proceed in adjusting spring tension
Installation on a Skyline GTS-t and GT-T (Diagrams from a R33 Skyline GTS-t)
1) Locate standard BOV on the inlet manifold. Remove the plumb back hose and vacuum nipple by removing the hose clamps.
Unbolt the BOV flange and remove the standard BOV.
Left side BOV vacuum line
Right side BOV vacuum line
Standard BOV
Plumb back hose
Vacuum hose
