24
96828 v.4.0
1.
Run the Diagnostic Port Harness
to the Tuner Harness. connect the
EconoMind Tuner and the Diagnostic
Port Harnesses to the Y-splitter.
You should feel the connectors lock
together. Secure the harnesses
away from hot and/or moving engine
components with zip ties.
CAUTION: When securing the
wires, do not bend them any
tighter than a 2.5” diameter bend
as this can cause undue stress on
the wires and can cause failure.
Pullers- skip to Step 4.
2.
Pushers- Locate the Extension
Harness in your kit. connect the
harness to the Y-splitter making
sure the connectors lock together.
Guide the harness through the
engine compartment to the bottom
of the coach. Route the harness to
the front and attach to the coach’s
undercarriage and existing wiring
harness using the supplied zip ties.
Keep the harness away from hot and/
or moving parts.
3.
Pushers- Connect the Extension
Harness to the cab Harness. The cab
Harness will go into your cab.
4.
Pullers- connect the cab Harness
to the Y-splitter. The cab Harness will
go into your cab.
5.
Pass the cab Harness into the cab
through an existing body grommet or
carefully drill a hole to access the cab
compartment (Optional).
6.
Optional: Know what is on the
other side of the drilling area before
drilling. Do not drill through any wires
or electrical equipment. Drill a 3 ⁄
8
” hole
and pass the cab Harness through the
cab. You may use a rubber grommet,
thick putty, or expandable spray
foam to help seal the hole against
the elements. You may find them at a
local hardware store.
7.
Reconnect the battery ground
cable(s).
8.
Double check everything to make
sure it is securely fastened and it
is not near any hot or moving parts
before starting engine.
-END SEcTION 8-
Section 8
Installation of EconoMind Tuner With Banks iQ
