22
96828 v.4.0
DynaFact gauges are a useful tool to
monitor vehicle performance. There is
a turbo boost gauge and an EGT gauge
that will measure exhaust temperatures.
1.
Run the Diagnostic Port Harness to
the Tuner Harness. Plug the Diagnostic
Port Harness into the Y-splitter. Use
the Jumper Harness to connect the
EconoMind and the Y-splitter together.
You should feel the connectors lock
together. Secure the Harnesses away
from hot and/or moving engine.
CAUTION: When securing the wires,
do not bend them any tighter than
a 2.5” diameter bend as this can
cause undue stress on the wires
and may cause failure.
Pullers- skip to Step 4.
2.
Pushers- Locate the Extension
Harness in your kit. connect the Harness
to the Y-splitter and guide the Harness
through the engine compartment to
the bottom of the coach. Make sure
the connectors lock together. Route
the Harness to the front and attach to
the coach’s undercarriage and existing
wiring harness using the supplied zip
ties. Keep the Harness away from hot
and/or moving parts.
3.
Pushers- Connect the Extension
Harness to the cab Harness. The cab
Harness will go into your cab.
4.
Pullers- connect the cab Harness to
the Y-splitter. The cab Harness will go
into your cab.
5.
Pass the cab Harness into the cab
through an existing body grommet or
carefully drill a hole to access the cab
compartment (Optional).
6.
Optional: Know what is on the other
side of the drilling area before drilling. Do
not drill through any wires or electrical
equipment. Drill a 3 ⁄
8
” hole and pass the
cab Harness through the cab. You may
use a rubber grommet, thick putty, or
expandable spray foam to help seal the
hole against the elements. You may find
them at a local automotive or hardware
store.
7.
choose a suitable location under
the lower edge of the dash or on top
for mounting the provided gauge panel
where the driver can conveniently view
it.
8.
Using the panel as a template, drill
two 3 ⁄
16
” diameter holes in the dash
and mount the panel with the supplied
machine screws, nuts and star washers
provided.
9.
Locate the supplied In-cab harness
with the 4-pin connector. See Figure
6. Plug the 4-pin connector into the
corresponding 4-pin receptacle from the
EconoMind.
10.
Install the DynaFact boost and
pyrometer gauges in the mounting
panel using the clamps and thumbnuts
provided. Plug the BLacK wire lead into
the male spade terminal on the BLacK
wire of each gauge wire harness. Plug
the YELLOW wire into the YELLOW wire
of the boost gauge wire harness and
the RED wire into the RED wire of the
pyrometer gauge wire harness. The
ORaNGE wire remains unused.
11.
connect the 4-pin connector
of each gauge into the back of its
corresponding gauge.
a. crimp the remaining BLacK and RED
wires from each 4-pin connector gauge
harness to the butt connectors as shown
in Figure 19.
b. Strip one end of the RED wire and
crimp to one of the butt connectors
attached to the gauge harnesses from
Step a.
c. Strip one end of the BLacK wire
and crimp to the other butt connector
attached to the gauge harnesses from
Step a.
Section 7
Installation of EconoMind Tuner with DynaFact Gauges
