REAR INSTALLATION
1. Chock the front wheels and jack up the rear of the Liberty. Place jack stands under the unibody frame
rails.
2. Using a 15mm socket remove the upper shock bolt. Using the 15mm and 18mm socket remove the
lower shock bolt. Remove the stock shock.
3. Remove the stock coil springs. Leave the stock bump stop in place.
4. Install the metal sleeve and small bushing on the top of the new Rough Country Shock as shown. Install
the top part of the shock as shown. Tighten to factory specs.
5. Install new coil springs small end towards the top.
6. Install the bottom of the new Nitro Shocks with factory bolts and tighten to factory specs
7. Using the floor jack lift the rear of the Liberty and remove the jack stands. Lower to the ground.
Tools Needed:
22mm Deep Well
19mm Deep Well
24mm Deep Well 24mm Wrench
15mm Deep Well 18mm Deep Well
Hammer Med. Alignment Spike
Floor Jack Pry bar
36mm Hub Socket 10mm Wrench
1/2” Ratchet 2 Jack Stands
Kit Contents:
2-Strut Extensions
2 Rear Gas Shocks
1 poly bag-Shock Hardware
1 Warning to Driver Decal
1 Rough County Windshield Decal
POST INSTALLTION NOTES
An alignment must be performed on vehicle after installation
Wheel lugs will need to retorqued after first 100 miles specs to factory specification.
