Rough Country RC800 User Manual
Page 4
10. Undo the clips on lower fan shroud pull down and remove. See Photo 13 & 14.
11. Using a 10mm remove ground wire from frame on driver side. See Photo 15.
12. Loosen all cab body mounts. On one side of the cab only, remove the bolts using a 18mm socket. See Photo 16.
Retain the factory hardware.
13. Using a 16mm remove nuts from body mounts. See Photo 17.
14. Using jack stand lift body slowly from the frame. See Photo 18.
PHOTO 13
PHOTO 14
PHOTO 15
PHOTO 16
PHOTO 17
PHOTO 18
UNCLIP FAN SHROUD
REMOVE THE LOWER FAN SHROUD
REMOVE THE GROUND WIRE
REMOVE CAB BOLTS (ONE SIDE ONLY)
REMOVE NUTS FROM CAB BODY MOUNTS
SLOWLY LIFT BODY
