Rough Country 585 - Manual (Page 6)

Photo 1
Photo 2
REAR INSTALLATION INSTRUCTIONS
(07-08 Only)
1. Chock the front wheels and jack up the rear of the vehi-
cle. Place jack stands under the frame rails and lower
the vehicle onto the jack-stands.
2. Remove the tires and wheels.
3. Using a 17mm wrench as shown remove the upper strut
nuts. See Photo 1. Retain the factory hardware.
4. Remove the rear brake line bracket from the strut mount
using a 10MM wrench. See Photo 2.
5. Remove the lower strut from the axle using a 30mm
socket and a 1 1/16” wrench. See Photo 3.
6. Using a strut compressor, compress the strut and remove the upper strut nut using a 15mm wrench as shown in
Photo 4. A wall mounted stationary strut compressor is shown but a non-mounted strut compressor may be used.
7. Remove the coil from the strut cartridge and install the new coil spacer as shown above the stock coil isolator. See
Photo 5.
Photo 4 Photo 5
Photo 3
