40. If reinstalling the stock stabilizer, install the sway bar on the drop brackets and shim plate as shown on the driver
side with the supplied 7/16” x 1 1/4” bolts, washers and lock nuts. Tighten using a 5/8” Wrench. See Photo 22.
41. Install the stabilizer in the bracket using the stock hardware. See Photo 23.
42. Using a 21mm wrench and 18mm wrench socket remove
the factory track bar bracket. Retain stock hardware for re-
use.
43. Position the Rough Country track bar bracket on the frame
as shown and secure using the factory hardware. Tighten
hardware using a 18mm wrench. See Photo 24.
44. Install the wheels/tires.
45. Jack up the vehicle and remove the jack stands.
46. Lower the vehicle to the ground and tighten the radius arm
bolts.
47. Line up the track bar with the hole in the new track bar
bracket. You may have to start the truck and turn the
wheels in the direction the track bar needs to go to help
align the track bar with the hole. Install using the stock
track bar bolt. Tighten bolt.
Photo 24
1. Chock front wheels and jack up the rear of the vehicle. Secure with jack stands on the frame rail.
2. Place a floor jack under the rear differential on the rear axle. Using a 18mm wrench for the upper, and 19mm and
15mm wrench for the lower, remove the stock shock absorbers, retain the stock hardware for re-use.
3. Remove the diff vent hose from the differential. See Photo 1.
4. Remove the diff vent tube using a 5/8” wrench. Retain the vent tube for re-use. See Photo 2.
REAR INSTALLATION
Photo 1 Photo 2
Photo 22 Photo 23
