BIDA 5800 & 5900 Series Two-Way Broadband Distribution Amplifiers
SPECIFICATIONS
RF Integrated Active
Return Path
5800 / 5900 BIDA 55A-30 BIDA 55A-30P BIDA 55A-43 BIDA 55A-43P BIDA 55A-50
Frequency Range (MHz): 5-36 / 5-42 49-550 49-550 49-550 49-550 49-550
Channel Loading: 3 77 77 77 77 77
Flatness (dB): ±0.5 ref to +1 dB tilt ±0.5 ±0.5 ±0.5 ±0.5 ±0.75
Hybrid Technology (dB): - Push-Pull Power Doubling Push-Pull Power Doubling Push-Pull
Gain (dB): 20 (Passive-1.5) 32 32 43 43 50
Noise Figure (dB) (a): 6 7.0 7.0 7.0 7.0 7.5
Output Level (dBmV): +42 +36/44 +36/44 +36/44 +36/44 +36/44
Test Port Level: Input/Output (dB): - -30, ±2 -30, ±2 -30, ±2 -30, ±2 -30, ±2
Composite Triple Beat - CTB (dB) (b): -60 -64 -71 -63 -68 -63
Cross Modulation - XMOD (dB) (b): -60 -67 -74 -66 -69 -60
Composite Second Order - CSO (dB) (b): -60 -61 -65 -60 -58 -65
SPECIFICATIONS
RF
BIDA BIDA BIDA BIDA BIDA BIDA BIDA BIDA BIDA
75A-30 75A-30 75A-43 75A-43P 86A/B-30 86A/B-30P 86A/B43 86A/B-43P 100A-30
5800/5900 5800/5900 5800/5900 5800-5900
Frequency Range (MHz): 49-750 49-750 49-750 49-750 47/54-86 47/54-860 47-54-86 47/54-86 49-1000
Channel Loading: 110 110 110 110 129 129 129 129 150
Flatness (dB): ±0.7 ±0.7 ±0.7 ±0.7 ±0.75 ±0.75 ±0.7 ±0.7 ±0.75
Hybrid Technology (dB): Push-Pull Power Push-Pull Power Push-Pull Power Push-Pull Power Push-Pull
Doubling Doubling Doubling Doubling
Gain (dB): 43 43 50 32 32 32 43 43 32
Noise Figure (dB) (a): 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5
Output Level (dBmV): 36/44 36/44 36/44 36/44 36/44 36/44 34/42 36/44 32/40
Test Port Level: Input/Output (dB): -30, ±2 -30, ±2 -30, ±2 -30, ±2 -30, ±2 -30, ±2 -30, ±2 -30, ±2 -30, ±2
Composite Triple Beat - CTB (dB) (b): -60 -64 -56 -64 -54 -62 -56 -60 -59
Cross Modulation - XMOD (dB) (b): -62 -68 -60 -68 -54 -62 -60 -65 -60
Composite Second Order - CSO (dB) (b): -56 -61 -59 -61 -57 -61 -59 -59 -59
Notes
(a) Measured at full gain with 8 dB slope (b) At rated output capability and channel loading (c) Power consumption varies by model / Range for all models provided
ORDERING INFORMATION
Model
Stock No. Description
BIDA 550-30 5400 53 Broadband Indoor Distribution Amplifier 30 dB, 47-550 MHz
BIDA 550-50 5400 55 Broadband Indoor Distribution Amplifier 50 dB, 47-550 MHz
BIDA 750-30 5400 73 Broadband Indoor Distribution Amplifier 30 dB, 47-750 MHz
BIDA 55A-30 5800 53 Broadband Indoor Distribution Amplifier 30 dB, 49-550 MHz, Integrated Active Return (5-36 MHz)
BIDA 55A-30P 5800P53 Broadband Indoor Distribution Amplifier 30 dB, 49-550 MHz, Integrated Active Return (5-36 MHz)
BIDA 55A-43 5800 54 Broadband Indoor Distribution Amplifier 43 dB, 49-550 MHz, Integrated Active Return (5-36 MHz)
BIDA 55A-43P 5800P54 Broadband Indoor Distribution Amplifier 43 dB, 49-550 MHz, Integrated Active Return (5-36 MHz),
BIDA 55A-50 5800 55 Broadband Indoor Distribution Amplifier 50 dB, 49-550 MHz, Integrated Active Return (5-36 MHz)
BIDA 75A-30 5800 73 Broadband Indoor Distribution Amplifier 30 dB, 49-750 MHz, Integrated Active Return (5-36MHz)
BIDA 75A-30P 5800P73 Broadband Indoor Distribution Amplifier 30 dB, 49-750 MHz, Integrated Active Return (5-36MHz)
BIDA 75A-43 5800 74 Broadband Indoor Distribution Amplifier 44 dB, 49-750 MHz, Integrated Active Return (5-36MHz)
BIDA 75A-43P 5800P74 Broadband Indoor Distribution Amplifier 43 dB, 49-750 MHz, Integrated Active Return (5-36MHz)
BIDA 86A-30 5800 83 Broadband Indoor Distribution Amplifier 30 dB, 49-860 MHz, Integrated Active Return (5-36MHz)
BIDA 86A-30P 5800P83 Broadband Indoor Distribution Amplifier 30 dB, 49-860 MHz, Integrated Active Return (5-36MHz)
BIDA 86A-43 5800 84 Broadband Indoor Distribution Amplifier 44 dB, 49-860 MHz, Integrated Active Return (5-36MHz)
BIDA 86A-43P 5800P84 Broadband Indoor Distribution Amplifier 44 dB, 49-860 MHz, Integrated Active Return (5-36MHz)
BIDA 86B-30 5900 83 Broadband Indoor Distribution Amplifier 30 dB, 54-860 MHz, Integrated Active Return (5-42MHz)
BIDA 86B-30P 5900P83 Broadband Indoor Distribution Amplifier 30 dB, 54-860 MHz, Integrated Active Return (5-42MHz)
BIDA 86B-43 5900 84 Broadband Indoor Distribution Amplifier 44 dB, 54-860 MHz, Integrated Active Return (5-42MHz)
BIDA 86B-43P 5900P84 Broadband Indoor Distribution Amplifier 44 dB, 54-860 MHz, Integrated Active Return (5-42MHz)
BIDA 100A-30 5800 13 Broadband Indoor Distribution Amplifier 30 dB, 49-1000 MHz, Integrated Active Return (5-36MHz)
Accessories
BIDA-CE-5 5475 BIDA Series Plug-In Cable Equalizer 550 MHz, Values: 3 ,6, 9 ,12, 15, 18 dB
BIDA-CE-7 5477 BIDA Series Plug-In Cable Equalizer 750 MHz, Values: 3, 6, 9 ,12, 15, 18 dB
BIDA-CE-8 5478 BIDA Series Plug-In Cable Equalizer 860 MHz, Values: 3, 6, 9, 12, 15, 18 dB
BIDA-CE-9 5479 BIDA Series Plug-In Cable Equalizer 1000 MHz, Values: 3, 6, 9, 12, 15, 18 dB
BIDA-FA 5411A BIDA Series Plug-In Fixed Attenuator,1000 MHz, Values: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20 dB
BIDA-RA 5402 BIDA Series Plug-In Return Amplifier 5-30 MHz
BIDA-RF 54071 BIDA Series Plug-In Return Filter, 5-30 MHz NOTE: For 5400 Series Amplifiers Only
