BIDA 5400 Series Broadband Distribution Amplifiers
SPECIFICATIONS
RF
BIDA-RF
Low High
BIDA-RA
BIDA 550-30
BIDA 550-50
BIDA 750-30
Frequency Range (MHz):
5-30 47-800
5-30
47-550
47-550
47-750
Channel Loading:
-
3
77
77
110
Flatness:
±0.25
±0.50
±0.75
±0.75
±1.00
Hybrid Technology (dB)::
-
-
Push-Pull
Push-Pull
Push-Pull
Gain (dB):
-0.50
24
33
50
31
Noise Figure (dB) (a):
-
6.0
7.0
7.0
9.0
Output Level - Max (dBmV):
-
+42
36/44
36/44
36/44
Test Port Level (dB):
-
-
-30, ±2
-30, ±2
-30, ±2
Gain Control Range (dB):
-
≥12
15
15
15
Slope Control Range (dB):
-
≥12
10
10
10
Composite Tripe Beat - CTB (dB) (b):
-
-60
-64
-64
-60
Cross Modulation - XMOD (dB) (b):
-
-60
-64
-64
-61
Composite Second Order - CSO (dB) (b):
-
-72
-64
-64
-61
Hum Modulation (dB):
-
-65
-70
-70
-70
Impedance - All Ports (Ohm):
-
-
75
75
75
Return Loss
Input (dB):
21 16
16
14
14
13
Output (dB):
21 16
16
14
14
13
Notes:
(a) Measured at full gain with 8 dB slope (b) At rated output capability and channel loading
ORDERING INFORMATION
Model
Stock No.
Description
BIDA 550-30
5400 53
Broadband Indoor Distribution Amplifier 30 dB, 47-550 MHz
BIDA 550-50
5400 55
Broadband Indoor Distribution Amplifier 50 dB, 47-550 MHz
BIDA 750-30
5400 73
Broadband Indoor Distribution Amplifier 30 dB, 47-750 MHz
Accessories
Model
Stock No.
Description
BIDA-RA
5402
BIDA Series Plug-In Return Amplifier 5-30 MHz
BIDA-RF
54071
BIDA Series Plug-In Return Filter, 5-30 MHz NOTE: For 5400 Series Amplifiers Only
