15 938H Wheel Loader specifications
Transmission
Forward 1 8.1 km/h 5 mph
Forward 2 14.6 km/h 9.1 mph
Forward 3 25.5 km/h 15.8 mph
Forward 4 43.2 km/h 26.8 mph
Reverse 1 8.1 km/h 5 mph
Reverse 2 14.6 km/h 9.1 mph
Reverse 3 25.5 km/h 15.8 mph
• Maximum travel speeds with empty bucket and 20.5-R25 tires.
Hydraulic System
Steering System Pump Type Piston
Hydraulic Cycle Time – Raise 5.4 Seconds
Hydraulic Cycle Time – Dump 1.4 Seconds
Hydraulic Cycle Time – Lower, 2.7 Seconds
Empty, Float Down
Hydraulic Cycle Time – Total 9.5 Seconds
Pilot System – Pump Output 295 L/min 77.9 gal/min
• Implement System (Standard), Piston Pump – Rated at
2,100 rpm and 1,000 psi (6900 kPa).
• Cycle time with rated payload.
Brakes
Brakes Meets required
standards
• Meet OSHA, SAE J1473 Oct90 and ISO 3450-1985 standards.
Axles
Front Fixed front
Rear Oscillating ±12°
Maximum Single-Wheel 420 mm 17 in
Rise and Fall
Engine
Engine Model Cat ® 6.6 ACERT™
Gross Power – SAE J1995 147 kW 197 hp
Net Power – ISO 9249 134 kW 180 hp
Net Power – SAE J1349 128 kW 172 hp
Net Power – 80/1269/EEC 134 kW 180 hp
Peak Torque (Net) @ 1,400 rpm 840 N·m 620 ft-lb
Total Torque Rise 38 %
Bore 105 mm 4.1 in
Stroke 127 mm 5 in
Displacement 6.6 L 402.8 in 3
• Caterpillar engine with ACERT™ Technology – EPA Tier III,
EU Stage III Compliant.
• These ratings apply at 2,100 rpm when tested under the
specified standard conditions.
• Rating for net power advertised based on power available
when the engine is equipped with alternator, air cleaner,
muffler and on-demand hydraulic fan drive at maximum
fan speed.
Weights
Operating Weight 15 059 kg 33,190 lb
• For 2.8 m 3 (3.65 yd 3 ) general purpose bucket with standard
20.5-R25 tires.
Buckets
Bucket Capacities 2.3 - 3.0 m 3 3.0 - 4.0 yd 3
Max Bucket Capacity 3 m 3 4 yd 3
Operating Specifications
Static Tipping Load, Full Turn 10 076 kg 22,207 lb
Breakout Force 123 kN 27,576 lb
• For 2.8 m 3 (3.65 yd 3 ) general purpose bucket with standard
20.5-R25 tires.
