• Comfortable operation
• Excellent visibility
• Easy entry and exit
• Low effort steering
OPERATING ENVIRONMENT. The 938H
provides operators with a comfortable
operating environment with generous
storage space and excellent visibility.
Seat. The durable seat adjusts 6-ways
to accommodate all sized operators.
The seat features an automotive style
lumbar support for maximum comfort.
The Cat C-500 Series Comfort air-
suspension seat is optional as is a
heated backrest and seat cushion.
Implement Pod. The newly restyled
implement pod provides superior comfort
through the full length adjustable
armrest. Standard transmission F-N-R
switch allows operators to keep their
hand on the implement control levers
while making directional shifts.
An optional joystick with integrated
F-N-R switch is available and replaces
the lift and tilt levers.
VISIBILITY. The 938H offers excellent
visibility to the front and rear of the
machine. Distortion-free flat glass
stretches to the floor of the cab for
excellent visibility to the bucket.
Wet-arm wipers on both front and back
keep the windows clean in any condition.
Rear Vision Camera. An optional rear
vision camera is available to clearly
monitor movement behind the wheel
loader.
Lighting Packages. In addition to the
standard roading lights, optional lighting
packages are available for low-light
applications. Optional auxiliary halogen
or High Intensity Discharge (HID) cab
lights provide exceptional lighting for
night work. A rotating beacon is
available as a safety feature.
ENTRY AND EXIT. A ladder with
aggressive tread pattern keeps debris
build-up to a minimum. The ladder is
at a 5° forward incline for easy entry
and exit.
The main cab door opens a full 180° and
latches in place to allow safe navigation
to the rear of the machine.
The right side door opens 10°, or
completely for secondary exit simply
by pulling a pin. A full-length ladder
on the right side facilitates safe exit
if needed.
Steering. Caterpillar’s low effort load
sensing steering directs power through
the steering system only when needed.
The new hand metering unit and priority
valve provide operators with full
steering and multi-function capability
a low engine RPM’s. The combined
steering column and instrument panel
tilt for maximum operator comfort.
Controls. Key machine controls are
conveniently located within arms reach
and allow better efficiency while
minimizing operator fatigue.
A variety of machine controls are also
contained within the Messenger display.
By accessing various menus, an operator
can tailor the machine to fit operating
style and application. For multi-shift
operations, personalized settings for
each operator can be established and
stored for maximum uptime and comfort.
SAFETY.CAT.COM™.
14
OPERATOR COMFORT
Work Comfortably and Efficiently
