Product key features

Product key features:
Atdec Global
www.atdec.com.au
Atdec North America
www.atdec.com
TH-3270-UFM
Full Motion | Large articulated arm
Mounting hole pattern:
from 150mm to 805mm wide
from 140mm to 500mm high
Maximum weight carrying capacity:
65kg (143lbs)
pantone 2915 C
cmyk 49,11,0,0
cmyk 0,0,0,100
®
®
Provides full range of movement via 3 pivot points
Smooth Glide™ technology for effortless movement
Detachable mounting head for easy installation and maintenance
Advanced cable management
All mounting hardware for masonry and timber stud installation included
Display can be installed in
Landscape or Portrait orientation
Minimum display distance from wall:
155mm (6.1”)
Maximum arm reach:
635mm (25”)
Adjustable tilt:
20° down and 10° up
Adjustable pan (at mounting head):
90° left and 90° right
Detachable mounting
head with security screw
to deter unauthorised
removal
Horizontal adjustment at the mounting
head: 5° on each side
The TH-3270-UFM is a full motion articulated wall mount that
combines cutting edge design with superior strength. It is capable
of supporting displays weighing up to 65kg (143lbs) as far as
635mm (25”) from the wall. The arm supports Full Motion capa-
bility due to its three pivot points that allow complete control over
tilt, pan, swing, arm extension and pivot. It combines Smooth
Glide technology™ and spring assisted tilting mechanisms to
ensure effortless display adjustment and the display can be
mounted in either portrait or landscape orientation. It supports a
wide variety of modern LED, LCD and Plasma displays thanks to
its universal mounting head and is shipping pre-assembled for
quick and easy installation.
