Atdec Telehook TH-31-55-SA-PK Technical specs User Manual
Flat screen wall mount | swing arm, Technical specifications, General features

14mm
(
9
/
16
”)
256mm
(10
1
/8”)
162mm
(6
3
/
8
”)
35mm (1
3
/
8
”)
MAXIMUM LLOAD: 65kg (143lbs)
DISPLAY C
COMPATIBILITY: Compatible with most VESA & non-VESA LCD/Plasma Flat screens with mounting hole configurations:
From 180mm to 685mm (7” to 27”) Wide;
From 100mm to 430mm (4” to 17”) High.
FASTENERS: All fasteners included.
WARRANTY: Limited 5 years. (Parts and workmanship)
Mounting Bracket
z
The Wall Bracket is to be installed vertically.
z
The Wall Bracket can be mounted to either:
-Timber Stud Wall, or
-Masonry Wall
TM
General Features
35mm (1
3
/
8
”)
180°
445mm (17½”)
Swing Arm Range of Movement
554mm
(22”)
100mm
(4”)
Distance from Wall
Dimensions
11mm
(
1
/
2
”)
180°
50mm (2”)
Side View
5
o
25
o
Technical Specifications
Flat Screen Wall Mount | Swing Arm
