TH-VWP-100 Dimensions
TH-VWP-160 Dimensions
Technical drawings
135mm
(5.3”)
300mm
(11.8”)
44.5mm (1.75”)
Wall to Screen
without Spacer
Wall to Screen
with Spacer
200mm
(7.87”)
Range: 90mm (3.74”)
to 100mm (3.94”)
300mm
(11.8”)
60.3mm (2.37”)
400mm (15.7”)
Ø20mm (0.79”)
29mm (1.1”)
43mm (1.69”)
51mm (2”)
Max Extension
57.5mm
(2.26”)
480mm (18.9”)
132.5mm
(5.21”)
TH-VWV Dimensions
