Maximum Weight:
70kg (154lbs)
Screen Mounting Compatibility:
From minimum 200mm wide x 200mm high to maximum 800mm wide x 400mm high.
Tilt Adjustment: Color: Warranty:
+ 15° Black 10 years
- 15°
Technical Specification TH-3070-UTP
Flat Screen Portrait Wall Mount | Tilt
General Features
Dimensions
+15° -15°
200-400mm
(7.9-15.7”)
200mm
(7.9”)
810mm
(31.9”)
832mm
(32.8”)
130mm
(5”)
Maximum Weight:
70kg (154lbs)
Screen Mounting Compatibility:
From minimum 200mm wide x 200mm high to maximum 800mm wide x 400mm high.
Tilt Adjustment: Color: Warranty:
+ 15° Black 10 years
- 15°
General Features
Dimensions
No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd.
Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. Published 25.01.13 ©
Wall Mounting:
Screen Mounting:
200-400mm
(7.9-15.7”)
200mm
(7.9”)
810mm
(31.9”) 832mm
(32.8”)
455mm
(17.9”)
421mm
(16.6”)
82mm
(3.2”)
223mm
(8.8”)
165mm
(6.5”)
109mm
(4.3”)
17mm
(0.7”)
63mm
(2.5”)
30.5mm
(1.2”)
8.5mm
(0.3”)
8.5mm
(0.3”)
Atdec Global www.atdec.com.au
Atdec North America www.atdec.com
Product information
Package information, single unit
Package information, master pack
Product Code
TH-2050-VFM
36cm x 35cm x 13cm
(14.25” x 14” x 5”)
38cm x 38cm x 54cm
(15” x 15” x 21.25”)
35kg (77lbs)
5.48kg (12.2lbs)
22.76kg (50.6lbs)
Die Cast Aluminium/Steel
881493004733
881493004689
Matt silver with black trim
All hardware required for
installation supplied
4
Load capacity
Size
Size
Ship weight
Ship weight
Material
UPC code
UPC code
Colour
Contents
Units per master pack
Atdec mounts are designed, developed and tested in Australia. While all efforts
have been made to ensure the information in this brochure was correct as of the
date of printing, we reserve the right to change specifications without notice. Please
refer to the website for our full range along with the latest details on specifications,
compatibility and dealer location. Atdec and Telehook are registered trademarks
with all rights reserved. Copyright May 2013.
Technical drawings
pantone 165 C
cmyk 0,59,96,0
pantone 186 PC cmyk 0,100,75,4
pantone 2915 C
cmyk 49,11,0,0 cmyk 0,0,0,100
cmyk 0,0,0,100
cmyk 0,0,0,100 ®
190°
360°
180°
240mm (9.45”)
194mm (7.64”)
Articulated Arm Range of Movement
Distance from Wall
Min.
100mm
(3.94”)
Max.
540mm
(21.26”)
Max. display
width at 90°
900mm
(35.43”)
50mm (2”)
offset from centre
Side View
-5°
+20°
