Page 7

Enter the holiday date, day of week and year by depressing

UP and DWN to

make the selection then depress

ENTER to accept.

Note: Holiday events will override all regularly programmed events that occur on a
particular holiday date.

Delete/Disable Events or Edit Events:
Select channel A or B by moving slide switch SW3 to appropriate position.
Note: Channel cannot be changed in the middle of programming events. To change channels
you must exit programming then change channel switch position then enter program mode again.
Previously programmed regularly scheduled and/or holiday events may be deleted/
disabled without having to erase all events.

Depress

SET until ENTER to

SET EVENT

Depress

ENTER

A01 ON

TU 00:00

Now scroll using

UP and DWN push buttons to the event you wish to delete, depress

ENTER to move flashing cursor under relay option then depress UP and DWN push
buttons until DIS is displayed, depress

ENTER to confirm.

G. Delete All Events:

This will delete all previously programmed events.

Depress

SET until

ENTER to

CLR MEM

Depress

ENTER

CLEAR

MEMORY?

Depress

ENTER

PRESS UP

& ACCEPT

Depressing

UP push button will now clear all events previously programmed.

If you wish to escape from this selection depress any of the other push buttons:
SET, ENTER and DWN.

H. Tandem Relay Mode:

To operate in the Tandem Relay Mode, close switch SW2. This mode setting will allow
events programmed for Channel A and Channel B to operate both relays simultaneously
(1 DPDT relay output). This setting doubles the amount of programmable events.

Note: When using the Tandem Relay mode, sequential ON/Off or OFF/ON events must be
programmed in the same channel. (If there is a Channel Program conflict, such as CH A is
set to ON and Channel B is set to OFF. The ON command will override the OFF and both
relays will remain ON.

- 7 -

appears in display.

will appear in display.

appears in display.
