Note: If pulse duration is not selected relay output defaults to 1 second.
Next select the individual day of the week by scrolling using
UP and DWN push buttons
and depress ENTER to accept.
Next select the hour and minutes the event is to occur by scrolling using UP and DWN
push buttons and depress ENTER to accept.
You may continue to program events by repeating the previous steps or exit programming by
depressing
SET.
Note: When programming additional events it is necessary to select the next consecutive
event number following the last event program to continue.
Note: When it is required to have the same event repeated on two (2) or more consecutive
days of the week, the event must be programmed as a block by selecting
BK in the day field.
A01 OFF
BK 00:00
Note: To program the consecutive days of the week refer to Setting Block Event (weekly
repeat) and Daylight Savings Time - section C1 below.
2. Adding Events
Depress SET until ENTER to
SET EVENT
Depress ENTER A01 OFF
SU 00:00
Depress ENTER , if the event is not programmed, the cursor will move to the OFF (relay function)
position. If the event is programmed the cursor will move to the position and the programmed
information of the event will be displayed. At this point depress the UP button to step up through
the programmed events. When an unprogrammed event is reached the cursor will move to the
OFF (relay function position). (At this point refer to setting events or setting holiday events.)
C. Setting Block Events (weekly repeat) and Daylight Savings Time:
Select channel A or B by moving slide switch SW3 to appropriate position.
Note: Channel cannot be changed in the middle of programming events. To change channels
you must exit programming then change channel switch position then enter program mode again.
Depress SET until ENTER to
SET BK
Depress ENTER A=SA/SU
TIME=DS
1. Block Event Programming
Flashing cursor will appear at the location of the first day of the week desired. Depress
UP and DWN to select day. Depress ENTER to confirm selection, then cursor will
appear at the location of the last day of the week desired. Depress
UP and DWN to
select day. Depress ENTER to confirm selection.
appears in display.
appears in display.
will appear in display.
will appear in display.
>
>
>
